Incoloy 800/800H/800HT Socket Weld Forged Fittings

Incoloy 800 Socket Weld Fittings, 800 Incoloy Socketweld Cap, Incoloy UNS N08800 Socketweld Coupling, Alloy 800H Socket weld Pipe Elbow, Incoloy 800H Socket Weld Cross, WERKSTOFF NR. 1.4876 Socketweld Fittings Manufacturer in India.

ASTM B564 Incoloy 800H Socketweld Elbow, Inconel 800H SW Laterial Tee, 800HT Alloy Forged Socket weld 90deg. Elbow, ASME SB564 Incoloy 800HT Socket weld Tee Suppliers in india.

We are Manufacturer, Supplier & Exporter of Incoloy 800/800H/800HT Socket Weld forged fittings. It is one of the best-forged fittings so you have to use it once. If you use it then you can easily know about its features and benefits. It is made from various materials but incoloy is found in a large way. It has mind-blowing features such as high strength, weldability, low conductivity, low maintenance and much more. We also offer the same in different grades such as Incoloy 800 Socket Weld Forged Fittings, Incoloy 800H Forged Socket Weld Fittings and so on. Incoloy Forged Socket Weld Fittings is a standard engineering material for applications which require resistance to corrosion and heat.

Recommended stress relieving temperature of 982 Degree C - 1010 Degree C for 1 hour in Incoloy 800/800H/800HT Forged Socket Weld Fittings yields the best performance. On the other hand, the manufacturing industries utilize the standard equipment and tools with the experience working panel of employees. The product is formed with the combination of the various elements that ensure the superior corrosion resistance as well as stress corrosion cracking. These Alloy UNS N08800 Forged Elbow are widely used in heat exchangers and other piping systems of industries. To avoid possible stress relaxation grain boundary cracking of Incoloy 800H Forged Socket Weld Tee Fittings in applications above 1000 Degree F, the welded fabrication may be heated 1650 Degree F for about one hour per inch of thickness or 30 minutes minimum then air cooled. This modification of Incoloy 800HT Forged Socket Weld Cap Fittings was to control carbon and grain size to optimize stress rupture properties.

Specification

Grade	Incoloy Alloy 800 / 800H / 800HT | UNS N08800 / N08810 / N08811
Standard	ASTM B564 & ASME SB564
Dimensions	ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size	1/8” NB to 4” NB
Class	2000 LBS, 3000 LBS, 8000 LBS, 9000 LBS
Form	Socket weld 45 deg Elbow, Socket weld 90 deg Elbow, Socket weld Tee, Socket weld Cross, Socket weld Cap, Socket weld Bend, Socket weld Coupling, Socket weld Union , Socket weld Bushing, Plug, Hex Plus, Hexagonal Plus, Lateral Tee.
Type	Socket weld Forged Fittings

Grade Specification

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	AFNOR	EN
Incoloy 800	1.4876	N08800	NCF 800	NA 15	ЭИ670	Z8NC32-21	X10NiCrAlTi32-20
Incoloy 800H	1.4958 / 1.4876	N08810	NCF 800H	NA 15(H)	ЭИ670	Z8NC33-21	X5NiCrAlTi31-20
Incoloy 800HT	1.4859 / 1.4876	N08811	NCF 800HT	NA 15(HT)	ЭИ670	–	X8NiCrAlTi32-21

Chemical Composition

Grade	C	Mn	Si	Al	S	Cr	Cu	Ni	Fe
Incoloy 800	0.10 max	1.50 max	1 max	0.15 – 0.60	0.015 max	19.0-23.0	0.75 max	30.0-35.0	39.5 min
Incoloy 800H	0.05 – 0.10	1.50 max	1 max	0.15 – 0.60	0.015 max	19.0-23.0	0.75 max	30.0-35.0	39.5 min
Incoloy 800HT	0.06 – 0.10	1.50 max	1 max	0.15 – 0.60	0.015 max	19.0-23.0	0.75 max	30.0-35.0	39.5 min

Mechanical Properties

Density	Melting Point	Tensile Strength	Yield Strength (0.2%Offset)	Elongation
7.94 g/cm3	1385 °C (2525 °F)	Psi – 75,000 , MPa – 520	Psi – 30,000 , MPa – 205	30 %
