Cu-Ni 90/10 Socket Weld Fittings, 90/10 Cu-Ni Socketweld Cap, Cu-Ni 90/10 Socket weld Pipe Elbow, 90/10 Cu-Ni Forged Socket weld 90deg. Elbow, Cu-Ni 90/10 WERKSTOFF NR. 2.0872 Socketweld Tee Manufacturer in India.
ASTM B467 Copper Nickel 90/10 Socketweld Elbow, ASME SB467 Cu-Ni90/10 Socket weld Tee, Cu-Ni 90/10 UNS C70600 Socketweld Coupling, Cupro Nickel 90/10 Socket Weld Cross Exporter in Mumbai,India.
We are Manufacturer, Supplier & Exporter of Copper Nickel 90/10 Socket Weld fittings which undergo forging which make them stronger and superior in-built and extremely reliable impact strength. Our ASTM B122 Copper Nickel 90/10 Socket Weld forged fittings are resistant to biofouling in sea water and brackish and brine waters, with excellent weldability and formability allowing for maximum utility under a wide range of temperature services. Cu-Ni 90 / 10 Forged Fittings (UNS C70600) to improve corrosion resistance in high-velocity waters, including seawater. Cupro Nickel 90 / 10 Forged Socket Weld Fittings contain 10-30 percent of nickel with addition of iron and manganese, which are necessary to maintain resistance towards corrosion.
Typically Cupro Nickel 90 / 10 Forged Threaded Fittings are used in sea water condenser systems. The main, wrought Copper Nickel 90 / 10 Forged Socket Weld Cap Fittings chosen for sea water service contain 10 percent nickel. Cu-Ni 90 / 10 Forged Socket Weld Coupling Fittings have good strength at moderately elevated temperatures. Cupro Nickel 90 / 10 Forged Socket Weld Cross Fittings can be fabricated by both hot and cold – working procedures, and is readily weld able. Our Cupro Nickel 90/10 Forged Socket Weld Fittings are fabricated by properly demonstrated plans and from the most noteworthy quality materials; which are then used for various Heavy Duty Applications like Condensers, Seawater piping, Power plants, Exchanger shells etc.
Specification
| Grade | Copper Nickel 90-10 | UNS C70600 |
| Standard | ASTM B122, ASTM B171, ASTM B466, ASTM B467 |
| Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8” NB to 4” NB |
| Class | 90-100 LBS, 3000 LBS, 90-100 LBS, 9000 LBS |
| Form | Socket weld 45 deg Elbow, Socket weld 90 deg Elbow, Socket weld Tee, Socket weld Cross, Socket weld Cap, Socket weld Bend, Socket weld Coupling, Socket weld Union , Socket weld Bushing, Plug, Hex Plus, Hexagonal Plus, Lateral Tee. |
| Type | Socket weld Forged Fittings |
Grade Specification
| STANDARD | WERKSTOFF NR. | UNS |
| Cupro Nickel 90/10 | 2.0872 | C70600 |
Chemical Composition
| Grade | Cu | Mn | Pb | Ni | Fe | Zn |
| Cupro Nickel 90/10 | 88.6 min | 1.0 max | 0.05 max | 9-11 max | 1.8 max | 1 max |
Mechanical Properties
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 0.323 lb/in3 at 68 F | 2260 F | 50000 psi | 20000 psi | 30 % |
Other Types of Copper Nickel 90-10 Socket Weld Forged Fittings
- Cupro Nickel 90/10 45 Socket Weld Elbow
- UNS C70600 Socketweld Tee
- 90/10 Cu-Ni Forged Socketweld Tee
- Cu-Ni Socket weld 90 Deg Elbow
- UNS C70600 Socket weld 90 Deg Elbow
- ASTM B122 TP 90/10 Copper Nickel Socketweld Cap
- ASME SB122 90/10 Copper Nickel 90 Degree Forged Socket Weld
- Cu-Ni 90/10Socket weld Coupling
- Copper Nickel 90/10 Socketweld Cross
- Cu-Ni 90/10 Forged Socket weld Cross
- UNS C70600 Socketweld Coupling
- 90/10 Copper Nickel Socket weld Coupling
- Copper Nickel 90/10 Socketweld Cap
- WERKSTOFF NR. 2.0872 Socket weld Coupling
