Monel 400 Pipe & Tubes

Monel 400 Rectangular Pipes, Monel UNS N04400 ERW Pipes, JIS NW 4400 Seamless Pipes, ASTM B 163 Round Pipes Manufacturer, DIN 2.4360 Hydraulic Tubes Suppliers in Mumbai,India.

ASME SB 165 Monel 400 Black Round Tubes, Monel 400 Polished Pipes, Monel 400 Welded Tubes, Monel Alloy 400 Square Pipes, Alloy 400 Capillary Tubes, Monel Alloy 400 EFW Tubing Manufacturer in Mumbai,India.

We are Manufacturer, Supplier & Exporter of Monel 400 Pipes and Tubes in Mumbai, India, that are being designed as per the national and international standard quality standards. Also known as UNS No N04400 Pipes & Tubes, it’s a nickel-copper alloy that is resistant to sea water and steam at high temperatures as well as to salt and caustic solutions. ASTM B161 / SB 163 Monel 400 Seamless Pipes & Tubes are a solid solution alloy that can only be hardened by cold working. Monel 400 bears excellent mechanical properties at sub-zero temperatures Our Monel 400 provides certain added advantages as compared to Monel 400 such as higher strength, as well as hardness owing to the addition of aluminium and titanium.

Monel 400 Tubes is the most extensively used precipitation supported version of the Nickel Copper family with controlled amounts of Titanium and Aluminium added during melting to the basic MONEL alloy 400 Tubes. As a result, Monel 400 EFW Pipes is used rarely -- and only when no other metal could do the same job. Monel 400 ERW Pipes can be machined at satisfactory rates with machine tools generally employed by industry. Monel 400 Seamless Tubes may be annealed at 926 Degree C (1700 Degree F). WNR 2.4360 Pipes and Tubes are resistant to corrosion and acids, and some alloys can withstand a fire in pure oxygen. They are stronger than steel and are also malleable in nature. We offer these Monel Alloy 400 products in custom-made shapes and sizes as per the requirements given by our clients, and that too at an affordable and market leading prices.

Specification

Grade	Monel 400 (UNS No. N04400)
Size	15"NB TO 150"NB IN
Standard	ASTM A163, ASME SB163
Range	6.35 mm OD upto 254 mm OD in 0.6 TO 20 mm thickness.
Form	Round, Square, Rectangular, Hydraulic Etc
Schedule	SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Length	Single Random, Double Random & Cut Length.
Type	Seamless / ERW / Welded / Fabricated / EFW
End	Plain End, Beveled End, Treaded

Grade Specification

STANDARD	UNS	WERKSTOFF NR.	AFNOR	EN	JIS	BS	GOST
Monel 400	N04400	2.4360	NU-30M	NiCu30Fe	NW 4400	NA 13	МНЖМц 28-2,5-1,5

Chemical Composition

Monel 400	Ni	C	Al	Mn	Si	Fe	Cu	S	Co	Cr
	63.0 min	0.3 max	0.50 max	2.0 max	0.5 max	1.0 – 2.5	28.0 – 34.0	0.02 max	–	–

Mechanical Properties

Density	Melting Point	Yield Strength (0.2%Offset)	Tensile Strength	Elongation
8.8 g/cm3	1350 °C (2460 °F)	Psi – 35,000 , MPa – 240	Psi – 80,000 , MPa – 550	40 %
